WHICH LEDGER BLADE TO USE?
Ledger blades influence the shearing result. It is therefore important to select the right blade.
For the perfect fit of the ledger blade according to your requirements please select from the following 3 basic properties:
LEDGER BLADE MATERIAL
| TYPE OF FABRIC | HL | H4 | POLYMANT |
|---|---|---|---|
| Cotton | x | x | x |
| Wool | x | x | x |
| Polyester | x | x | |
| Technical textiles | x | ||
| Material properties | high-alloyed tool steel 57-59 HrC |
optimised high-alloyed tool steel 59-61 HrC |
metallurgical steel 61-64 HrC |
THICKNESS OF THE LEDGER BLADE
| TEXTILES TO BE PROCESSED | THICKNESS OF LEDGER BLADE IN MM |
|---|---|
| Combed yarn/ carded yarn |
3 |
| Embroideries | 3 - 4 |
| Flat woven fabric | 3 - 4 |
| Plush | 4 |
| Velour | 4 |
| Circular knitting plush/fleece | 4 |
| Blankets | 4 |
| Carpet | 5 - 6 |
| Fleece | 4 - 5 |
| Sisal, coconut fibre | 4 |
| Synthetic fibres | 4 - 5 |
COMPOSITION OF THE LEDGER BLADE
| OVERALL LENGTH | 50 - 6500 mm |
| HOLES | round, oval etc. as per customer requirements |
| WIDTH | 50 - 500 mm |
